Views: 0 Author: Site Editor Publish Time: 2026-07-09 Origin: Site
Rating | Solid Particle Protection | Water Protection | Typical Test |
IP54 | Dust-protected (limited ingress) | Splashing water from any direction | Water spray at 10 L/min for 5 min |
IP65 | Dust-tight (no dust ingress) | Low-pressure water jets | Water jet at 12.5 L/min from 3m |
Cost Factor | IP54 | IP65 | Premium |
Enclosure fabrication (per kg) | Baseline | +5-10% | Better sealing, gasket channels |
Sealing/gaskets | Cheap foam gasket | Silicone + compression latches | +15-25% |
Ventilation system | Passive grilles (low cost) | Active cooling (medium-high) | +20-50% |
Total enclosure cost (50 kWh) | $800-1,200 | $1,200-1,800 | 30-50% higher |
Installation Environment | Recommended Rating | Rationale |
Indoor, climate-controlled | IP54 (or lower) | Dust protection sufficient |
Outdoor, shaded (building side) | IP54 | Ventilation benefits outweigh water risk |
Outdoor, direct rain | IP54 (rain shield) or IP65 | Risk assessment needed |
Coastal / high humidity | IP65 (conformal coating) | Salt spray + condensation |
Flood-prone areas | IP65 minimum, IP67 recommended | Submersion risk |
